Designing passive solar gain into a new build

The principles of passive solar gain

Passive solar gain is the art of capturing warmth from the sun without relying on mechanical systems. In a new build, you have the rare chance to get this right from the very first sketch. The three pillars are orientation, glazing and thermal mass. Unlike active solar panels, passive design uses the building itself as the collector and store. For a UK climate, the goal is to welcome low winter sun deep into the home while blocking the high summer sun. Get it wrong, and you either shiver or overheat. Get it right, and your home feels comfortable, costs less to run, and needs less energy to heat. The beauty is that these are not expensive add-ons; they are decisions about shape, direction and materials.

Orientation: the one decision you cannot change

Once your foundations are in, orientation is fixed. So spend time on the site before you design. In the UK, true south is your friend. Aim to place your main living spaces, such as the kitchen, dining and living room, within 30 degrees of due south. Bedrooms, bathrooms and utility rooms can happily face north, where they will stay cooler in summer and lose less heat in winter. Avoid large east or west-facing windows if you can: the low morning and evening sun is hard to shade and can cause uncomfortable glare and overheating. Use a sun path diagram for your latitude to see exactly how the sun moves. Also check for overshadowing from neighbouring buildings, trees or hills. A south-facing plot that is shaded by a tall evergreen will not perform as well as an open one. If you are renovating a period property, you have to work with what you have, but for a new build, this is your first and most powerful tool.

Glazing: where gain meets loss

Windows are the delicate balance of passive solar design. They let warmth in, but they also let it out. In a new build, specify high-performance glazing. Triple glazing with low-emissivity coatings and argon or krypton fill is now the benchmark, with whole-window U-values of 0.8 W/m²K or better. But do not simply fill your south wall with glass. A useful rule of thumb is to keep south-facing glazing to around 15–20% of the total floor area of the room. Any more and you risk overheating in shoulder seasons and excessive heat loss at night. Frame choice matters too: thermally broken timber or uPVC frames reduce cold bridging. For period properties, you would typically retrofit secondary glazing or slim double glazing, but in a new build you can design the window sizes and positions for optimal performance from day one. Remember that north-facing glazing should be minimised and well insulated, as it gains almost nothing but loses plenty.

Thermal mass: storing the warmth for later

Thermal mass is the heavyweight of passive solar design. Materials like concrete, brick, stone, and tile absorb heat during the day and release it slowly as the temperature drops. To work, the mass must be inside your insulated envelope and exposed to the sun. A polished concrete floor slab or an internal brick wall in a south-facing room is ideal. Avoid covering these surfaces with thick carpets or lightweight plasterboard, which insulate the mass and stop it working. The classic mistake is to build a lightweight timber frame with lots of south glazing and no mass – the result is a greenhouse that overheats by day and freezes by night. A well-designed new build might use a concrete floor slab, a masonry internal wall, or even a water-filled thermal store. The key is to let the winter sun strike the mass directly, then let the mass radiate warmth back into the room for hours after sunset.

Shading and summer overheating

Passive solar gain is not just about winter warmth; it is also about preventing summer overheating. UK summers are getting hotter, and a home that captures too much sun can become unbearable. The simplest solution is a fixed overhang or reveal. For a south-facing window, calculate the depth so that it blocks the high summer sun (around 21 June) but allows the low winter sun (around 21 December) to reach the glass. As a rule, an overhang of about 0.5 metres for a 2.4-metre-high window works well in southern England, but you should fine-tune for your latitude. For east and west windows, overhangs are less effective because the sun is low. Use external adjustable blinds, shutters, or deciduous trees instead. Internal blinds are a poor second, as the heat has already passed through the glass. Also plan for cross ventilation – openable windows on opposite sides of the house – to purge warm air on summer evenings.

Bringing it together: a practical checklist

Passive solar design is a whole-house approach, not a bolt-on. Use this checklist as you plan your new build:

Orient main living spaces within 30 degrees of due south.
Limit south glazing to around 15–20% of the room’s floor area.
Specify triple glazing with a whole-window U-value of 0.8 W/m²K or better.
Add thermal mass in sunlit floors and walls – exposed concrete, brick or stone.
Design overhangs to block summer sun but welcome winter sun.
Plan cross ventilation for summer night purging.
Commission an airtightness test and aim for a fabric-first approach.

If you are renovating a period property, many of these principles still apply, but you will need to adapt them to existing walls, windows and orientations. The joy of a new build is that you can design passive solar gain in from the very beginning, creating a home that is warm in winter, cool in summer, and gentle on the planet.
